Robot Battery Manufacturer
Best robot battery for AGVs, AMRs, drones, cleaning, welcoming, underwater, agricultural,ย industrial, medical…
Drones
AGVs/RGVs
Cleaning robot
Industrial robot
Medical robot
Service robot
Agricultural robot
Why Tritek?
- ๐๐๐ซ๐ฌ๐๐ญ๐ข๐ฅ๐ ๐๐จ๐ฅ๐ญ๐๐ ๐ ๐๐ฉ๐ญ๐ข๐จ๐ง๐ฌ: Offers ๐๐๐, ๐๐๐, ๐๐๐, ๐๐๐, and more to support diverse robotic applications.
- ๐๐จ๐ญ-๐๐ฐ๐๐ฉ๐ฉ๐๐๐ฅ๐ ๐๐ฎ๐ฉ๐ฉ๐จ๐ซ๐ญ: Allows seamless battery replacement without interrupting equipment operation.
- ๐๐ฎ๐ฅ๐ญ๐ข-๐๐๐ญ๐ญ๐๐ซ๐ฒ ๐๐๐ซ๐๐ฅ๐ฅ๐๐ฅ ๐๐ฎ๐ฉ๐ฉ๐จ๐ซ๐ญ: Configures from ๐-๐๐ batteries in parallel to maximize operational range.
- ๐๐จ๐ฆ๐ฉ๐๐ญ๐ข๐๐ฅ๐ ๐๐จ๐ฆ๐ฆ๐ฎ๐ง๐ข๐๐๐ญ๐ข๐จ๐ง: ๐๐๐ ๐ฉ๐ซ๐จ๐ญ๐จ๐๐จ๐ฅ compatibility for reliable data exchange.
- ๐๐ฅ๐จ๐๐๐ฅ ๐๐๐ซ๐ญ๐ข๐๐ข๐๐๐ญ๐ข๐จ๐ง๐ฌ: ๐๐, ๐๐๐, ๐๐๐๐.๐, ๐๐, ๐ ๐๐, and more for international safety and quality assurance.
- ๐๐ง๐ ๐๐ญ๐จ๐ฉ ๐๐จ๐ฅ๐ฎ๐ญ๐ข๐จ๐ง: BMS, battery packs, lithium chargers, ODM/OEM, you can get all you need!
Best Lithium Robotic Battery Manufacturer 2025
48V LFP Robot Battery TP6068
- Power: 48V, 30Ah, 1440Wh
- Size: 297*87*415.7mm
- Weight: 13.88 kg
- Hot swapping: 2-11 parallel
- Discharge current: 30A standard, 60A max, 100A peak
48V LFP Robot Battery TP6087
- Power: 48V, 15Ah, 720Wh
- Size: 297*87*275mm
- Weight: 9 kg
- Hot swapping: 2-11 parallel
- Discharge current: 15A standard, 30A max, 58A peak
48V NCM Robot Battery TP6094
- Power: 48V, 30Ah, 1440Wh
- Size: 297*87*358mm
- Weight: 10.75 kg
- Hot swapping: 2-11 parallel
- Discharge current: 30A standard, 60A max, 100A peak
48V NCM Robot Battery TP6088
- Power: 48V, 20Ah, 960Wh
- Size: 297*87*279mm
- Weight: 5.64 kg
- Hot swapping: 2-11 parallel
- Discharge current: 20A standard, 40A max, 66A peak
Discover more robot lithium-ion battery option—>
Want a customized mobile robot battery?
100-day Promise!
Get Your Custom Batteries in a Blink, Pledge for Safety and Quality
1. Customer idea (3-7 days)
- Product designย
- Project planning
2. Design output (7-14 days)
- Designย failure modeย and effect analysis
- Costing
3.Sampling (30 days)
- DFMEA
- Function validation
- Reliability validation
- Certificate validation
4.Pre-series (20 days)
- Pre-series reviewย
- Material approval
- Golden sample approval
- Certificate, SOP
5. Mass production (35 days)
- Six Sigma
- Total quality management
- Customer service
Customer-oriented Design > IATF16949:PPAP,QCP > Perfect Battery Products
What Makes Tritek's Robot Battery Your First Choice?
Safety From Cell, BMS to Battery Pack
Top Cell Only
- Top-tier battery cell only, Samsung, LG, CBAK.
- Cell test forced discharge test, overcharge test, 25ยฐC short-circuit performance test, crush test, impact test, heating test, projectile test, etc.
In-house Battery Management System
- Full Circuit and Function Test: Over 90% test coverage for accurate batatery monitoring
- Dual Protection: Robust hardware and firmware dual safeguards
- Precise SOC Management: Accurate insights into battery capacity
- Comprehensive protection: Overcharge, over-discharge, over-temperature, short circuit, etc
- Smart Monitoring and Communication Interface: Real-time battery status monitoring, calendar information, short circuit protection, CAN bus communication, and HMI display
In-house and Third-Party Test
- Each battery pack will conduct various tests before shipping to assure safety. 0 fire or explosion so far.
- In house test: Charge and discharge, high and low temperature, functional, EOL test.
- The Third-Party Test: Short circuit, high temperature, ESD, IP67 dust and water proof, vibration, consistent temperature and humidity test.
Excellent Thermal Management
- Integrated NTC to monitor BMS and cell temperature
- Discharge thermal rise test
IP67 Certified
- With Tritek’s IP67 certified robotic battery, no concerns in any environments.
Request a Quote for More Details
Intelligence Everywhere
Hot-swappable Multi Battery Solution
- Hot swappable without interrupting equipment operation.
- Support up to 11 batteries in parallel, up to 36 kWh for extended runtime.
- Modular desgin, both vertical and horizontal parallel are available
Low Power Consumption
- 2 years of charge-free storage at 20% SOC.
We Know Your Certification Need
All You Need To Know About Robot Batteries
How to Choose the Right Battery for Your Robot?
Battery Type (NCM, LFP, etc.)
Firstly, choose the battery type fit for your robot application.
- NCM: Higher energy density, lightweight, small size. Ideal for robots requiring minimal weight or compact size, such as mobile robots.
- LFP: Higher power density, longer lifespan, safer, and cheaper. It suits applications where robots may face intense usage, high-power tasks, or high-temperature environments, such as heavy-duty or industrial robots.
Capacity and Runtime
Capacity, measured in Ah (Ampere-hours) or kWh (Kilowatt-hours), directly impacts runtime. Higher capacities allow robots to operate longer between charges, especially critical for robots performing continuous or heavy-duty tasks.
Size and Weight
Space constraints often limit battery size, so choose compact options if size is a concern. Weight is especially crucial for mobile robots; lighter batteries help maintain agility, whereas stationary robots may accommodate heavier options.
Discharge Current
Continuous and peak discharge current ratings should align with the robot’s energy draw. High-drain applications require batteries with high discharge capabilities to avoid performance issues, such as voltage drops during demanding tasks.
Communication Protocols
CAN bus, RS485, or UART protocols allow the battery to communicate with the robotโs systems, offering real-time data on battery status. CAN protocol is particularly robust for industrial and high-demand applications, allowing smoother data exchange.
Voltage Requirements
Choose a voltage that aligns with the robot’s power demands. Typical options include 36V, 48V, 60V, and 72V.
- Lower voltage (e.g., 36V, 48V): suited for AGVs (Automated Guided Vehicles), light-duty service robots, and collaborative robots (cobots), etc.
- Higher voltage (e.g., 60V, 72V): suited for heavy-duty industrial robots, outdoor robots (like agricultural or construction robots), and large, autonomous mobile robots (AMRs), etc.
Tritek 48V LFP Battery
Tritek 72V NCM Battery
Additional Features
- Hot-Swappable: Hot-swappable Batteries allow quick replacement without stopping operations, essential for robots with high uptime demands.
- Multi-Battery Parallel Support: For applications needing extra capacity, parallel support extends runtime.
- IP67 Protection: Ensures the battery is resistant to dust and water, suitable for outdoor or rugged environments.
- 4G and Bluetooth Connectivity: Enables remote monitoring, diagnostics, and data exchange, crucial for real-time control and maintenance.
- Over-the-Air (OTA) Updates: Keep firmware up-to-date with OTA, which simplifies updates and ensures the batteryโs software remains current with the latest features and protections.
FAQ
Is Tritek a trading company or factory?
Tritek is a company with our factory, integrating R&D, production, and sales.
What is the MOQ?
200pcs.
Can I custom robot battery?
Yes, we are specialist in custom lithium batteries, we offer LFP and NCM battery cells, various voltage ranges, CAN/RS485/UART communication protocol... Our skilled engineers excel at designing battery solutions that fit seamlessly into compact spaces.
How are Tritek batteries shipped, and are they compliant with transportation regulations?
Tritek batteries adhere to UN38.3 and other regulatory standards for the safe transportation of lithium batteries. We ensure secure packaging and certified handling, allowing for compliant and safe shipping to international destinations.
