Light Electric Vehicle Batteries
Custom lithium battery solutions for e-bikes, e-motorcycles, e-mopeds, cargo bikes, tricycles, quadricycles, hoverboards…
Commuter bike
City bike
E-mountain bike
Electric moped
Electric motorcycle
Electric scooter
Cargo bike
Why Tritek?
- Versatile Voltage Options: Offers 36V, 48V, 60V, 72V and more to support diverse LEV applications.
- Hot-swappable Support: Allows seamless battery swapping without interrupting equipment operation.
- Multi-Battery Parallel Support: Configures from 2-11 batteries in parallel to maximize operational range.
- Compatible Communication: CAN protocol compatibility for reliable data exchange.
- Global Certifications: UL, IEC, UN38.3, CE, FCC, and more for international safety and quality assurance.
- One Stop Solutions: BMS, battery packs, lithium chargers, battery swap station, ODM/OEM, you can get all you need!
Explore Our Light Electric Vehicle Battery Solutions
Lightweight and compact lithium battery solutions for urban, trekking, mountain, and other electric bicycles.
High-power battery packs designed for electric motorcycles, with customized voltage, capacity, discharge performance, and intelligent BMS.
Durable lithium battery solutions for electric mopeds, balancing range, power, weight, and vehicle integration.
High-capacity battery solutions for cargo bikes and commercial delivery applications requiring long operating time and reliable power output.
| Model | Chemistry | Voltage | Capacity | Power | Dimension | Weight |
|---|---|---|---|---|---|---|
| TP6028 | NCM | 48V | 6.8Ah | 326.4Wh | D50.5*530mm | 1.95kg |
| TP6172 | NCM | 36V | 11Ah | 396Wh | 477*50.7*50.7mm | 2.2kg |
| TP6159-01 | NCM | 36V | 13.6Ah | 489.6Wh | 355*78.4*65mm | 2.8kg |
| TP6159-02 | NCM | 48V | 10.2Ah | 489.6Wh | 355*78.4*65mm | 2.7kg |
| TP6136N1 | NCM | 36V | 14.7Ah | 529.2Wh | 420*70*64.5mm | 3.0kg |
| TP6136N2 | NCM | 36V | 16.5Ah | 594Wh | 420*70*64.5mm | 3.2kg |
| TP6137N1 | NCM | 48V | 9.8Ah | 470.4Wh | 420*70*64.5mm | 2.9kg |
| TP6137N2 | NCM | 48V | 11Ah | 528Wh | 420*70*64.5mm | 3.12kg |
| TP6138N1 | NCM | 36V | 19.6Ah | 705.6Wh | 420*70*76mm | 3.7kg |
| TP6138N2 | NCM | 36V | 22Ah | 792Wh | 420*70*76mm | 3.8kg |
| TP6139N1 | NCM | 48V | 14.7Ah | 705.6Wh | 420*70*76mm | 4.0kg |
| TP6139N2 | NCM | 48V | 16.5Ah | 792Wh | 420*70*76mm | 4.14kg |
| TP6173-02 | NCM | 48V | 22Ah | 1056Wh | 409*95*86mm | 5.1kg |
| TP6126 | NCM | 48V | 14.7Ah | 705.6Wh | 409*95*86mm | 5.1kg |
| TP6176-02 | NCM | 36V | 22Ah | 792Wh | 366.8*97*97mm | 3.9kg |
| TP6178-02 | NCM | 48V | 16.5Ah | 792Wh | 366.8*97*97mm | 3.8kg |
| TP6080 | NCM | 36V | 4.9Ah | 176.4Wh | D78.5*210mm | 1.25kg |
| TP6125 | NCM | 48V | 4.9Ah | 235.5Wh | D78.5*210mm | 1.6kg |
| TP6171 | NCM | 36V | 6.5Ah | 234Wh | D78.5*210mm | 1.6kg |
| TP6125-04 | NCM | 48V | 6.5Ah | 312Wh | D78.5*210mm | 1.7kg |
| TP6068 | LFP | 48V | 30Ah | 1440Wh | 415.7*297*87mm | 13.88kg |
| TP6087 | LFP | 48V | 15Ah | 720Wh | 275*297*87mm | 9.0kg |
| TP6094 | NCM | 50.4V | 29.6Ah | 1491.84Wh | 358*297*87mm | 10.75kg |
| TP6088 | NCM | 46.8V | 19.6Ah | 917.28Wh | 279*297*87mm | 5.64kg |
| TP6140-1 | NCM | 61.2V | 29.4Ah | 2142Wh | 330*200*130mm | 13.5kg |
| TP6140-1 | NCM | 72V | 34.3Ah | 2160Wh | 330*200*130mm | 13.5kg |
| TP6140-2 | LFP | 73.6V | 24Ah | 1766.4Wh | 330*200*130mm | 13kg |
| TP6140-2 | LFP | 73.6V | 20Ah | 1472Wh | 330*200*130mm | 12.5kg |
| TP6110 | LFP | 73.6V | 45Ah | 3312Wh | 260*165*386mm | 26kg |
Want a customized lev battery?
100-day Promise!
Get Your Custom Batteries in a Blink, Pledge for Safety and Quality
1. Customer idea (3-7 days)
- Product design
- Project planning
2. Design output (7-14 days)
- Design failure mode and effect analysis
- Costing
3.Sampling (30 days)
- DFMEA
- Function validation
- Reliability validation
- Certificate validation
4.Pre-series (20 days)
- Pre-series review
- Material approval
- Golden sample approval
- Certificate, SOP
5. Mass production (35 days)
- Six Sigma
- Total quality management
- Customer service
Customer-oriented Design > IATF16949:PPAP,QCP > Perfect Battery Products
Why LEV Batteries Need Customization
Custom Voltage & Capacity
Battery voltage and capacity can be configured according to vehicle and range requirements.
High Power Output
Cell selection and battery architecture can be optimized for continuous and peak current requirements.
Intelligent BMS
Battery monitoring, protection, SOC management, and communication functions can be customized.
Compact Design
Cell configuration, enclosure dimensions, connectors, and mounting structures can be designed around available space.
Thermal Management
Battery design considers current load, operating conditions, heat generation, and thermal performance.
Communication
CAN, UART, RS485, and other communication interfaces can be integrated according to system requirements.
Why Choose Tritek
China's Pioneering Manufacturer
- 15+ years in custom solutions
- 100+ successful partnerships
Guaranteed Safety & Quality
- Use top cells from Samsung, Sony, LG, and Panasonic
- ISO 9001 and IATF 16949 certified, product UL, IEC, UN certified
Exceptional Customer Support
- Expert assistance in custom assembly design and engineering
- After-sales service centers in Germany and Spain
Request a Quote for More Details
We Know Your Certification Need
Safety, Quality & Compliance
Battery testing and compliance support are provided according to the application and target market.
FAQ
Is Tritek a trading company or factory?
Tritek is a company with our own factory, integrating R&D, production, and sales.
What is the MOQ?
200pcs.
Can Tritek customize a battery for a specific electric vehicle?
Yes. Tritek provides custom battery development based on the vehicle's electrical, mechanical, thermal, and communication requirements. OEM customers can provide requirements such as voltage, capacity, motor power, dimensions, current, connector specifications, and communication protocol.
How are Tritek batteries shipped, and are they compliant with transportation regulations?
Tritek batteries adhere to UN38.3 and other regulatory standards for the safe transportation of lithium batteries. We ensure secure packaging and certified handling, allowing for compliant and safe shipping to international destinations.
Tritek Off-the-shelf Light Electric Vehicle Batteries
TP6176/TP6178
36V/48V Ebike Battery
TP6173
48V Ebike Battery
TP6172
36V Ebike Battery
TP6159-01 /TP6159-02
36V/48V Ebike Battery
TP6138N1/N2 /TP6139N1/N2
36V/48V Ebike Battery
TP6136N1/N2 /TP6137N1/N2
36V/48V Ebike Battery
TP6126
48V Ebike Battery
TP6042
50.4V Ebike Battery
TP6080 / TP6125
36V / 48V Ebike Battery
TP6028
48V Ebike Battery
TP6023
72V E-moped / E-motorcycle Battery
TP6140
72V E-moped / E-motorcycle Battery
TP6110
72V E-moped / E-motorcycle Battery
TP6088
46.8V Cargo Bike Battery
TP6087
48V Cargo Bike Battery
TP6094
50.4V Cargo Bike Battery
