Specialized Application Batteries
Custom lithium battery solutions for demanding and application-specific equipment.
Oxygenerator
Patient Monitor
Agricultural Robot
Autonomous Sprayer
Underwater ROV
Marine Fish Finder
More Application
Why Tritek?
- Versatile Voltage Options: Offers 24V, 36V, 48V, 60V, 72V and more to support diverse applications.
- Hot-swappable Support: Allows seamless battery swapping without interrupting equipment operation.
- Multi-Battery Parallel Support: Configures from 2-11 batteries in parallel to maximize operational range.
- Compatible Communication: CAN protocol compatibility for reliable data exchange.
- Global Certifications: UL, IEC, UN38.3, CE, FCC, and more for international safety and quality assurance.
- One Stop Solutions: BMS, battery packs, lithium chargers, battery swap station, ODM/OEM, you can get all you need!
Explore Our Speicalized Application Battery Solutions
Battery Solutions Designed for Specialized Applications
Different applications create very different battery requirements.
A medical device may prioritize compact size and reliable operation. Agricultural equipment may require high power and resistance to demanding outdoor conditions. Marine equipment may require protection against moisture and corrosion.
Our specialized application batteries are developed around the actual operating environment, power requirements, available space, and system architecture of your equipment.
Agricultural Equipment Battery
Custom lithium battery packs for electrically powered agricultural equipment and machinery.
Typical requirements include:
- High power output
- Long operating time
- Outdoor operation
- Vibration resistance
- Dust and water protection
- Intelligent BMS
Medical Equipment Battery
Compact and reliable lithium battery solutions for portable and battery-powered medical equipment.
Typical requirements include:
- Compact design
- High energy density
- Stable power output
- Accurate battery monitoring
- Reliable protection
- Application-specific certification requirements
View Medical Equipment Batteries →
Marine Lithium Battery
Battery solutions for marine equipment and electrically powered systems operating in demanding environments.
Typical requirements include:
- High energy capacity
- Moisture protection
- Corrosion-resistant design
- Reliable BMS protection
- Long cycle life
- Application-specific communication
View E-moped Batteries →
Custom & Specialized Applications
Custom battery solutions for equipment with unique electrical, mechanical, environmental, or communication requirements.
Typical Applications
- Specialized mobile equipment
- Portable and battery-powered equipment
- Autonomous and intelligent machines
- Outdoor and off-road equipment
- Custom automation systems
- New or emerging battery-powered applications
| Model | Chemistry | Voltage | Capacity | Power | Dimension | Weight |
|---|---|---|---|---|---|---|
| TP6028 | NCM | 48V | 6.8Ah | 326.4Wh | D50.5*530mm | 1.95kg |
| TP6172 | NCM | 36V | 11Ah | 396Wh | 477*50.7*50.7mm | 2.2kg |
| TP6159-01 | NCM | 36V | 13.6Ah | 489.6Wh | 355*78.4*65mm | 2.8kg |
| TP6159-02 | NCM | 48V | 10.2Ah | 489.6Wh | 355*78.4*65mm | 2.7kg |
| TP6136N1 | NCM | 36V | 14.7Ah | 529.2Wh | 420*70*64.5mm | 3.0kg |
| TP6136N2 | NCM | 36V | 16.5Ah | 594Wh | 420*70*64.5mm | 3.2kg |
| TP6137N1 | NCM | 48V | 9.8Ah | 470.4Wh | 420*70*64.5mm | 2.9kg |
| TP6137N2 | NCM | 48V | 11Ah | 528Wh | 420*70*64.5mm | 3.12kg |
| TP6138N1 | NCM | 36V | 19.6Ah | 705.6Wh | 420*70*76mm | 3.7kg |
| TP6138N2 | NCM | 36V | 22Ah | 792Wh | 420*70*76mm | 3.8kg |
| TP6139N1 | NCM | 48V | 14.7Ah | 705.6Wh | 420*70*76mm | 4.0kg |
| TP6139N2 | NCM | 48V | 16.5Ah | 792Wh | 420*70*76mm | 4.14kg |
| TP6173-02 | NCM | 48V | 22Ah | 1056Wh | 409*95*86mm | 5.1kg |
| TP6126 | NCM | 48V | 14.7Ah | 705.6Wh | 409*95*86mm | 5.1kg |
| TP6176-02 | NCM | 36V | 22Ah | 792Wh | 366.8*97*97mm | 3.9kg |
| TP6178-02 | NCM | 48V | 16.5Ah | 792Wh | 366.8*97*97mm | 3.8kg |
| TP6080 | NCM | 36V | 4.9Ah | 176.4Wh | D78.5*210mm | 1.25kg |
| TP6125 | NCM | 48V | 4.9Ah | 235.5Wh | D78.5*210mm | 1.6kg |
| TP6171 | NCM | 36V | 6.5Ah | 234Wh | D78.5*210mm | 1.6kg |
| TP6125-04 | NCM | 48V | 6.5Ah | 312Wh | D78.5*210mm | 1.7kg |
| TP6068 | LFP | 48V | 30Ah | 1440Wh | 415.7*297*87mm | 13.88kg |
| TP6087 | LFP | 48V | 15Ah | 720Wh | 275*297*87mm | 9.0kg |
| TP6094 | NCM | 50.4V | 29.6Ah | 1491.84Wh | 358*297*87mm | 10.75kg |
| TP6088 | NCM | 46.8V | 19.6Ah | 917.28Wh | 279*297*87mm | 5.64kg |
| TP6140-1 | NCM | 61.2V | 29.4Ah | 2142Wh | 330*200*130mm | 13.5kg |
| TP6140-1 | NCM | 72V | 34.3Ah | 2160Wh | 330*200*130mm | 13.5kg |
| TP6140-2 | LFP | 73.6V | 24Ah | 1766.4Wh | 330*200*130mm | 13kg |
| TP6140-2 | LFP | 73.6V | 20Ah | 1472Wh | 330*200*130mm | 12.5kg |
| TP6110 | LFP | 73.6V | 45Ah | 3312Wh | 260*165*386mm | 26kg |
Want a customized battery?
Application Challenges
System Communication
The BMS can be configured to communicate with the equipment controller through interfaces such as CAN, UART, or RS485.
Application-Specific Safety Requirements
Battery design and testing can be aligned with the safety and regulatory requirements applicable to the target application and market.
Limited Installation Space
Battery dimensions, mounting points, connectors, and cable routing can be customized to fit the available space.
High Power Requirements
Cell configuration and electrical architecture can be designed around continuous and peak current requirements.
Challenging Environments
Battery design can take into account factors such as moisture, dust, vibration, temperature, and outdoor operation.
100-day Promise!
Get Your Custom Batteries in a Blink, Pledge for Safety and Quality
1. Customer idea (3-7 days)
- Product design
- Project planning
2. Design output (7-14 days)
- Design failure mode and effect analysis
- Costing
3.Sampling (30 days)
- DFMEA
- Function validation
- Reliability validation
- Certificate validation
4.Pre-series (20 days)
- Pre-series review
- Material approval
- Golden sample approval
- Certificate, SOP
5. Mass production (35 days)
- Six Sigma
- Total quality management
- Customer service
Customer-oriented Design > IATF16949:PPAP,QCP > Perfect Battery Products
Why Batteries Need Customization
Voltage & Capacity
Configure battery voltage, capacity, and energy according to your equipment's power and runtime requirements.
Cell Selection
Select suitable lithium-ion cell chemistry, format, capacity, and performance characteristics for the application.
Intelligent BMS
Customize battery protection, monitoring, SOC estimation, communication, and other BMS functions.
Environmental Protection
Battery construction can be designed for application-specific requirements such as water, dust, vibration, and temperature.
Mechanical Design
Customize dimensions, housing, mounting points, connectors, and interfaces for mechanical integration.
Communication
Integrate battery communication with the equipment control system according to your interface and data requirements.
Why Choose Tritek
Application-Based Customization
Battery design starts with your equipment requirements rather than a one-size-fits-all specification.
Integrated BMS Development
Battery, BMS, communication, and protection functions can be developed as an integrated system.
Engineering Support
Support throughout electrical, mechanical, BMS, prototype, testing, and production stages.
Flexible Battery Design
Customize voltage, capacity, cell configuration, dimensions, connectors, and communication according to the application.
Quality Manufacturing
Controlled manufacturing and testing processes help ensure consistent battery performance.
Global B2B Support
Support for OEMs, equipment manufacturers, and system integrators developing battery-powered products for international markets.
Request a Quote for More Details
Designed with Safety & Compliance in Mind
Battery safety and regulatory requirements vary by application and target market. We consider applicable standards and certification requirements during battery development and validation.
Certification and compliance are evaluated according to the battery design, application, and target market.
FAQ
Is Tritek a trading company or factory?
Tritek is a company with our own factory, integrating R&D, production, and sales.
What is the MOQ?
200pcs.
Can Tritek customize batteries for specialized equipment?
Yes. Tritek can customize battery voltage, capacity, cell configuration, dimensions, connectors, BMS functions, communication interfaces, and other battery characteristics according to the equipment requirements.
What specialized applications can Tritek support?
Tritek can develop battery solutions for applications such as agricultural equipment, medical equipment, marine systems, and other specialized equipment requiring customized battery designs.
What information should I provide for a custom battery project?
Useful information includes required voltage, capacity, continuous and peak current, operating time, charging method, battery dimensions, operating environment, communication requirements, connectors, and target market.
Tritek Off-the-shelf Batteries
TP6176/TP6178
36V/48V Battery
TP6173
48VBattery
TP6172
36V Battery
TP6159-01 /TP6159-02
36V/48V Battery
TP6138N1/N2 /TP6139N1/N2
36V/48V Battery
TP6136N1/N2 /TP6137N1/N2
36V/48V Battery
TP6126
48V Battery
TP6042
50.4V Battery
TP6080 / TP6125
36V / 48V Battery
TP6028
48V Battery
TP6023
72V Battery
TP6140
72V Battery
TP6110
72V Battery
TP6088
46.8V Battery
TP6087
48V Battery
TP6094
50.4V Battery
